Shimano’s Ultegra Di2 handles shifting with electronic precision. Vision Trimax Carbon Aero bars and Cannondale C1 Conceal stem shape a low, efficient front end, while Ultegra hydraulic discs stay predictable when pace compresses and corners come in hot. Built to make the surge stick.
Features:
| FRAMESET: | |
| Frame: | SuperSix EVO Carbon, Gen 5, integrated cable routing, 12x142 thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, UDH |
| Fork: | SuperSix EVO Carbon, Gen 5, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm) |
| Headset: | Integrated, 1-1/8" - 1-1/4" |
| DRIVETRAIN: | |
| Rear Derailleur: | Shimano Ultegra Di2 R8150, 12-speed |
| Front Derailleur: | Shimano Ultegra Di2 R8150 |
| Shifters: | Shimano Ultegra Di2 R8170, wireless, 2x12-speed |
| Chain: | Shimano Ultegra, 12-speed |
| Crank: | Shimano Ultegra R8100, 52/36: 165mm (44-50cm), 170mm (52-56cm), 172.5 (58-61cm) |
| Rear Cogs: | Shimano Ultegra R8100, 11-30, 12-speed |
| Bottom Bracket: | Shimano BB-RS500, BSA 68 |
| BRAKES: | |
| Brakes: | Shimano Ultegra R8170 hydraulic disc, 160/140mm CL800 rotors |
| Brake Levers: | Shimano Ultegra Di2 R8170 hydraulic disc |
| WHEELS: | |
| Front Hub: | DT Swiss 370, 12x100mm centerlock |
| Rear Hub: | DT Swiss 370 LN Ratchet System, 12x142mm centerlock |
| Rims: | DT Swiss ERC LOG 45, carbon, 22mm inner width, 45mm depth, 24h, tubeless ready |
| Spokes: | DT Swiss Competition |
| Wheel Size: | 700c |
| Tires: | Schwalbe One TLR, 700x28c, tubeless ready |
| COMPONENTS: | |
| Handlebar: | Vision Trimax Carbon Aero: 380mm (44-56), 400mm (58-61) |
| Stem: | Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44cm), 90mm (48-52cm), 100mm (54-56cm), 110mm (58-61cm) |
| Grips: | Cannondale Bar Tape, 3.5mm |
| Saddle: | Fizik Vento Antares R5, S-Alloy rails, 140mm |
| Seatpost: | Cannondale C1 Aero 40 Carbon V2, 365mm, 0mm offset (44-54cm), 15mm offset (56-61cm) |
| Wheel Sensor: |
