Designed to go fast, built to go long, and made to keep you comfortable, the Synapse redefines road performance. With a lightweight frame featuring wind-tunnel-sculpted tubing and PB-blasting stiffness-to-weight, it’s a bike that’s ready for anything you demand of it. Just ask Lachlan Morton why he trusted it for his record-smashing lap of Australia. Unreal speed, engineered for real-world roads. With advancements in our carbon layup, our engineers have made the new Synapse 20% more compliant than its already butter-smooth predecessor, ensuring you feel 100% more comfortable even on the roughest roads. A great fit and feel makes for a great ride. And with our Proportional Response Construction, every rider gets that as standard. From the carbon layup through to the geometry, everything on Synapse has been tuned and tested by frame size. So that your bike works in harmony with you to give the best possible ride for you and your height.
| FRAMESET: | |
| Frame: | Synapse Carbon, Proportional Response construction, integrated cable routing, downtube Stashport, 12x142 thru-axle, UDH, BSA 68mm threaded BB, flat mount disc, integrated seat binder, SmartSense Gen 2.0 compatible, fender mounts |
| Fork: | Synapse Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/5" Delta steerer, 55mm offset, fender mounts |
| Headset: | Integrated, 1-1/8" - 1-1/2" |
| DRIVETRAIN: | |
| Rear Derailleur: | Shimano 105 Di2 7150 |
| Front Derailleur: | Shimano 105 Di2 7150, braze-on |
| Shifters: | Shimano 105 Di2 R7170, wireless, 12-speed |
| Chain: | Shimano 105 7100, 12-speed |
| Crank: | Shimano 105 7100, BSA, 50/34: 165mm (44cm), 170mm (48-51cm), 172.5 (54-56cm), 175mm (58-61) |
| Rear Cogs: | Shimano 105 7100, 11-34, 12-speed |
| Bottom Bracket: | Shimano BSA 68 |
| BRAKES: | |
| Brakes: | Shimano 105 7170 hydraulic disc, 160/160mm RT70 rotors |
| Brake Levers: | Shimano 105 Di2 7170 hydraulic disc |
| WHEELS: | |
| Front Hub: | Shimano RS470, 12x100mm centerlock |
| Rear Hub: | Shimano RS470, 12x142mm centerlock |
| Rims: | DT Swiss R470 DB, 28h |
| Spokes: | Stainless Steel, 14g |
| Wheel Size: | 700c |
| Tires: | Vittoria Rubino Pro IV, 700x32c |
| COMPONENTS: | |
| Handlebar: | Vision Trimax Aero Alloy: 400mm (44-51cm), 420mm (54-61cm) |
| Stem: | Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44-48m), 90mm (51cm), 100mm (54-56cm), 110mm (58-61cm) |
| Grips: | Cannondale Bar Tape, 3.5mm |
| Saddle: | Fizik Vento Argo X5, 140mm |
| Seatpost: | Cannondale C1 Aero 27 Carbon, SmartSense compatible, 330mm length, 0mm offset (44-48cm), 15mm offset (51-61cm) |
| Wheel Sensor: |
