At just 1.92 kg, the TQ HPR60 system is the lightest, quietest, and smallest in its class. With 60Nm of torque, 350W of maximum power, and 200% support, it’s a mid-power drive system that focuses on opti mal power-to-weight ratio and maximum efficiency. At 580Wh, the battery has a higher capacity than other drive systems of its size, and with near invisible integration and unchanged bike kinematics you can hardly tell it’s there.
The same confidence-inspiring suspension as the rest of the Sight family, VPSHP is the ideal high pivot all-mountain setup with smooth, efficient pedaling and confident handling in rough, steeper terrain.
| FRAMESET: | |
| Frame: | Carbon Frame, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fork: | Fox 36 Performance Elite GripX2, HSC/LSC/HSR/LSR, 160mm, 44mm Offset, Fender Included |
| Rear Shock: | Fox Float X Performance, 230x60mm Std, 2 position |
| DRIVETRAIN: | |
| Rear Shifter: | Shimano Deore Di2 SW-M6250-IR, 12sp |
| Rear Derailleur: | Shimano Deore Di2 RD-M6250, SGS, 12sp |
| Crankset: | e*thirteen Helix Race Alloy TQ, 34T, 155mm (S1,S2) - 160mm (S3,S4,S5) |
| Bottom Bracket: | |
| Cassette: | Shimano Deore CS-M6100-12, 10-51T, 12sp |
| Chain: | Shimano Deore CN-M6100, 12sp |
| BRAKES: | |
| Front Brake: | Shimano Deore M6120 4-P, Metallic pads |
| Front Brake Rotor: | Shimano SM-RT86, 203mm, 6-Bolt |
| Rear Brake: | Shimano Deore M6120 4-P, Metallic pads |
| Rear Brake Rotor: | Shimano SM-RT86, 180mm, 6-Bolt |
| Brake Levers: | Shimano Deore M6100 |
| COMPONENTS: | |
| Handlebar: | Norco 6061 DB Alloy, 800mm, 25mm Rise |
| Stem: | Norco Alloy, 40mm Length, 35mm Clamp |
| Seatpost: | TranzX YSI08 RAD+ Travel Adjust Dropper, 31.6mm, 125mm (S1) -150mm (S2) -170mm (S3) -200mm (S4, S5) |
| Headset: | FSA No.55 Sealed Bearing, 1 1/8" - 1.8" Tapered, ( ZS44/28.6 | ZS56/40 ) |
| Saddle: | WTB Rocket Fusion Med, 142x250 mm |
| Grips: | WTB Wavelength, 140mm Length |
| WHEELS: | |
| Front Hub: | Crank Bros. Synthesis, 15x110mm Boost, 32h, 6-Bolt |
| Rear Hub: | Crank Bros. Synthesis, 12x148mm Boost, Micro Spline, 32h, 6-Bolt |
| Rims: | Crank Bros. Synthesis Alloy Enduro, F- 31.5mm 28h, R- 29.5mm 32h, 29"-27.5" F/R |
| Front Tire: | Continental Kryptotal-F, Enduro, Soft, 29" x 2.4", Foldable |
| Rear Tire: | Continental Xynotal, Enduro, Soft, 27.5" x 2.4", Foldable |
| Spokes/Nipples: | Sapim D-Light (front), Sapim Race (rear) |
| ELECTRIC COMPONENTS: | |
| Drive Unit: | TQ HPR60, 60 Nm |
| Battery: | TQ 580Wh |
