Shimano’s CUES 10-speed drivetrain makes shifting smooth and reliable, and Tektro hydraulic disc brakes bring confidence to every descent. With a 130mm dropper post for instant seat adjustments, Trail 1 is proof that decades of innovation can deliver first-class performance, one ride at a time.
Features:
| FRAMESET: | |
| Frame: | Trail, SmartForm C3 Alloy, 142x12mm, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, KickFlip hidden 18mm 2-bolt kickstand mount port, BSA-73, 27.5" wheels (XS, S) / 29" wheels (M, L, XL) |
| Fork: | SR Suntour XCM Boost, coil, 100mm travel, 46mm offset (29"), 80mm travel, 42mm offset (27.5") |
| Headset: | Semi-Integrated, 1-1/8" |
| DRIVETRAIN: | |
| Rear Derailleur: | Shimano CUES U6000 |
| Shifters: | Shimano CUES U6000, 10-speed |
| Chain: | KMC X10, 10-speed |
| Crank: | Prowheel, Charm 30T |
| Rear Cogs: | Shimano CUES, 11-48, 10-speed |
| Bottom Bracket: | ProWheel, square taper |
| BRAKES: | |
| Brakes: | Tektro M275 hydraulic disc, 160/160mm rotors |
| Brake Levers: | Tektro hydraulic disc |
| WHEELS: | |
| Front Hub: | Shimano TC500, 15x110mm |
| Rear Hub: | Shimano TC500, 12x142mm |
| Rims: | WTB SX19, 32h |
| Spokes: | Stainless Steel, 14g |
| Tire Size: | 2.25 |
| Wheel Size: | 27.5/29 |
| Tires: | Trail Boss 27.5x2.25" (XS,S) / 29x2.25" (M, L, XL) Comp, 30 TPI |
| COMPONENTS: | |
| Handlebar: | Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm |
| Stem: | Cannondale 4, 6061 Alloy, 31.8, 6° |
| Grips: | Cannondale |
| Saddle: | Cannondale Trail |
| Seatpost: | JD Dropper, internal routing, 31.6, 130mm |
